Hobbywing EZRUN 1/5 56118SD 650KV Motor G2

Beschrijving

Hobbywing EZRUN 1/5 56118SD 650KV Motor G2

Features

• Compared with the previous generation, ithas added a new waterproof sensor cable, upgraded to a sensored system, with better accelerate linearity and stronger explosive force.
• It has perfect compatibility when it is matched with HobbywingEZRUN MAX5 G2 ESC, the esc can automatically recognize this motor, and build a power system with full sensor mode, providing better control performance and more delicate control feel, and also realizing the motor overheat protection function.
• The independent high-precision encoder always outputs pure rotor position signal, which effectively avoids the interference of sensor signal and makes the motor work stably in sensor state.
• CNC machined aluminum housing, high purity copper windings, high strength explosion-proof rotor, ultrathin silicon steel laminations, high-quality stainless steel output shaft, high-precision bearing for high durability and smoothness.
• The innovative new sensor interface and rubber cover bearing have better waterproof and dustproof effect than the traditional sensor motor.

Specifications
KV:650KV
LiPo’s:8-12S
No-Load Current:5.5A
Diameter / Length:56mm (2.20″) 30mm (1.18″)
Shaft Diameter / Length:8mm (0.31″) 30mm(1.18″)
Bearing SIze (mm): Front:D22*D8*T7 Rear: D19*D8*T6
Poles:4
Weight:1272g
Applications:1/5th Buggy, Truck
